Render Sfere Per-cad-cam GUAINA LOGO



The Single Threaded Sphere attachment for bar connections is manufactured with a 1.6 mm thread, 2 sided titanium bonding sleeve, and a base spacer. This new system offers laboratories two cost effective options for placing the attachment on CAD/CAM milled or cast bar overdenture connections.
Technicians can select between screwing the Single Threaded Sphere directly into a milled site, or use the base spacer and bonding sleeve with traditional casting techniques which eliminates the need for drilling and tapping. Once the bar is cast, the Single Threaded Sphere and sleeve are screwed together and bonded directly into the attachment location.
The Single Threaded Sphere kit comes complete with 2 titanium nitrate coated attachments, 2 titanium bonding sleeves, 2 base spacers, an assortment of caps and 2 stainless steel housings.












Single threaded sphere

 139KSFN

Ref. 139KSFN

Single Threaded Sphere Normal - With TiN Coating
With Sleeve For Bonding
Hex 1.3 mm Thread 1.6 mm

Kit Contains:
- 2 Titanium Normal Single Threaded Spheres
- 2 Titanium Threaded Sleeves
- 2 Stainless Steel Spacers for Threaded Sleeves (standard)






139KSFM

Ref. 139KSFM

Single Threaded Sphere Micro - With TiN Coating
With Sleeve For Bonding
Hex 0.9 mm Thread 1.6 mm

Kit Contains:
- 2 Titanium Micro Single Threaded Spheres
- 2 Titanium Threaded Sleeves
- 2 Stainless Steel Spacers for Threaded Sleeves (micro)






239SFN

Ref. 239SFN

Single Threaded Sphere w/Titanium Nitrate Coating
Standard 1.3mm Diameter Hex, 1.6 mm Thread






239SFM

Ref. 239SFM

Single Threaded Sphere w/Titanium Nitrate Coating
Micro 0.9mm Diameter Hex, 1.6 mm Thread








239GSF

  Ref. 239GSF

 Titanium Sleeve 1.6 mm Thread








239SSNRef. 239SSN   Stainless Steel Spacer For Threaded Sleeve - Standard


239SSMRef. 239SSM   Stainless Steel Spacer For Threaded Sleeve - Micro


760CBR



Ref. 0760CBR - Hex Driver For Threaded Sphere
Standard Hex 1.3 mm






772CSF

   Ref. 772CSF - Hex Driver For Threaded Sphere

   Micro Hex .9 mm
