OT Vertical

OT Vertical is a cylindrical attachment that works by friction, suitable for partial dentures and bar connections. The castable plastic pin is used as a parallelometer key and, after casting, as a centering pin to connect and balance the prosthesis during the insertion phase, especially when there are no counter-milling operations. The male metal and female nylon components are available with a length of 5mm, but can be reduced, without changing the functionality up to a length of 3.5mm. The reference of these two lengths facilitates the replacement of the elastic clip (female) by the dentist.
OT vertical-COMP

product info
studio
laboratory
product specifications
Videos and Documents

Product Informations

Scatola OT VERTICAL 071OBVRef. 0710BV

OT VERTICAL
Kit contains:
• 4 CALCINABLE MASKS
• 2 STEADY
• 4 WHITE RETENTIVE CLIPS
• 2 GREEN RETENTIVE CLIPS
• 4 CERAMIC BARS
• 4 KEY FOR PARALLELOMETER +
CALCINABLE PLUG

Maschiochiave 072MCV
Ref. 072MCV

Kit Contains
- 2 Castable Males
- 2 Pin Keys

Steady-Calcinabile 072SCVRef. 072SCV

Kit Contains
- 2 Castable Steady

Barretta-Ceramica 072BCVRef. 072BCV

Kit Contains
- 2 Ceramic Bars

Clip Bianca 072CBVRef. 072CBV

Kit Contains
- 4 White Clips - Standard Retention

Clip verde 072CVVRef. 072CVV

Kit Contains
- 4 Green Clips - Soft Retention

Tools

Inseritore-estrattore VerticalRef. 472ICV    - TOOL FOR INSERTING OT BAR MULTIUSE CLIPS

Studio

Otvertical-1

Skeleton melted and sand

Otvertical-2

Skeleton finished, insertion of the Retentive Clip using the appropriate inserter

Otvertical-3

Otvertical-4

Skeletonized on the model.
Technically functional even without milling, thanks to the balancing pin

OTvertical 5

The vertical and the retentive clips can be lowered in height, in order not to risk inconveniences, it is advisable not to shorten them beyond the indicative sign of 3.5 mm.

Laboratory

Extract the CLIP from the container using
a metal tool

Check to see if the previous CLIP
it was whole or shortened to 3.5 mm

If it is necessary to shorten it, use a cutter
adequate and consume it up to the mark indicated on the back

With the appropriate INSERATOR, apply the new CLIP (whole or shortened)

The attack and the clip can be
mounted whole (5 mm) or shortened
(3.5 mm) always limiting the part
opposite to the hole

Parallelogram wrench: insert the plug into the hole of the attachment, rotate a few times to obtain the correct seal and be able to slide it out comfortably after fixing the attachment in the wax.

Completed the assembly and the wax modeling insert the ceramic cylinder in the hole of the attachment and melt

Blast the melt, to remove
the ceramics remained in the hole to use
a ball cutter or an acid
adequate

Before duplicating the model in
coating, cut from the key of the
parallelometer the tip of the pin
made of plastic from the rest of the stem

Insert the sectioned plastic plug
in the hole of the attack and pour the material
to duplicate (silicone or jelly)

In the model reproduced in cladding,
the plastic (calcinable) plug, can
be removed or remain inserted in the
coating

Skeleton modeled,
proceed to the merger

Skeleton melted and sanded

Finished skeleton, insertion of the clip
retentive using the appropriate inserter

Skeletonized on the model.
Technically functional even without
milling, thanks to the molten plug of
balancing
